本机采用“自动侦测织物厚薄感知系统”,拥有更高效的生产性能及优质的缝制品质,另外拓展了缝制范围、缝制花样更是达到50个。一方面装备了电子夹线器(电子夹线机构)、自动抬压脚机构,扩大缩小机能使得可在启缝点处进行调整,从而具备更佳的操作性能:另一方面配备有信赖性优越的控制箱,使用简便地操作控制盘。
Using the "auto-detect the fabric thickness and sensing systems", with more efficient production of high quality sewing performance and quality, while expanding the scope of the sewing, sewing patterns reached 50. On the one hand line equipped with electronic devices folder(electronic folder line agencies),automatic foot lift pressure institutions to expand the function of making narrow slit in the sew point adiustment, which have better performance.on the other hand, is equipped with superior reliability the control box, easy to use control panel to operate.

| 机型Machine type | GT-1900ASS | GT-1900AHS | GT-1900AGS | GT-1900AGP |
| 类别Category | 基本缝 Basic made | 厚料Heavy weight. | 花样缝 Pattern Sewin | 拼接缝Elastic Joint |
机针 Machine needle | DPx5 14# | DPx17 21# | DPx17 14# | DPx17 14# |
抬压脚高度 Foot lifter height | 14-17 | 14-17 | 10 | 10 |
针杆行程 Needle bar stoke | 41.2 | 41.2 | 41.2 | 41.2 |
| 旋梭Rotating hook | 卧式标准旋梭 Horizontal hook(standard) | 卧式标准旋梭 Horizontal hook(standard) | 卧式标准旋梭 Horizontal hook(standard) | 卧式标准旋梭 Horizontal hook(standard) |
可缝尺寸(mm) Can be the size of sewing | 纵30x横40 | 纵30x横40 Vertical 30x40 Sidelong | 纵30x横40 Vertical 30x40 Sidelong | 纵30x横40 Vertical 30x40 Sidelong |
缝迹长度(mm) Sewing thread of length | 0.1-10 | 0.1-10 | 0.1-10 | 0.1-10 |
最高转速(rp.m) Max speed | 3000 | 3000 | 2700 | 2700 |
包装尺寸 Package size | 805x405x525 | 805x405x525 | 805x405x525 | 805x405x525 |
毛重/净重 Gross/net weight | 55/64 | 55/64 | 55/64 | 55/64 |
